acme thread rolling machine Description
ACME thread rolling machine thread roller is divided into two axis rolling machine and three axis thread rolling machine
1, two axis wire rolling machine has very strong superiority in hardware building, automobile and motorcycle fittings, traffic power, standard parts.
2, three axis rolling machine is triangle support in the pipe thread processing industry, true fidelity roundness, concentricity and perpendicularity
It is a multifunctional cold extrusion rolling thread machine, the workpiece in the cold rolling pressure range can be made to straight lines, twill, spur, helical and bevel gear spline rolling; straightening, necking, rolling light and various rolling forming. The machine has safe and reliable electric liquid control system and implementation, which can make each work cycle in manual, semi-automatic and automatic selection in three ways. The cold rolling is an advanced non cutting process, which can effectively improve the internal and surface quality of workpiece, the radial compressive stress produced during processing, and can significantly improve the fatigue strength and torsion strength of the workpiece. It is an ideal process with high efficiency, energy saving and low consumption.
The ACME thread rolling machine thread roller can equipped the auto feeding and loading machine. pls inquiry for details.
Z28-150B steel bar thread rolling machines pecification sheet
|
Items |
Parameters |
|
|
diameter |
φ5-φ48mm |
|
|
thread pitch |
5.0mm |
|
|
Spindle Angle |
±8° |
|
|
Maximum rolling pressure |
180kn |
|
|
Spindle RPM |
Exchange gear 37/46/63/79rpm |
|
|
Thread rolling wheel range |
diameter |
φ120-φ170mm |
|
aperture |
φ54mm |
|
|
Maximum width |
100mm |
|
|
Spindle drive power |
5.5kw |
|
|
Hydraulic transmission power |
2.2kw |
|
|
Physical size |
1520×1400×1450mm |
|
|
Machine weight |
1600kg |
|
FAQ
1. Do you have any warranty for ACME thread rolling machine?
Yes, we have. Two years warranty on host machine is given. Six months free replacement warranty for spare parts.
2. How is your after-sale service?
We have a professional technology supporting team for your timely services. You can get the help you need in time by telephone, webcam, online chat (Google talk, Facebook, Skype). Please contact us once the machine has any problem. Best service will be offered.
3. What certification of rebar screw thread rolling machine do you have?
All of our machines have the CE certification which ensures the quality and safety. Our machines are under strict quality management to ensure good quality. Because we fully understand that it will be a great trouble if machine have any problem during working at oversea.
4. Will you teach how to use the drywall screw making machine?
Yes, we can provide a complete user manual and usage video for instruction and application. And 24/7 online consultant service ensure you whatever problem and whenever you meet, you can solve easily. It is easy to operate by anyone with the instructions.
5. How about the shipment?
The machine will be shipped within 2-3 days after the receipt of your payment.
6. Can visit your factory?
Welcome to our factory. We would like to make invitation letter for you. Hope we can cooperate with you for a long term.
